ROQ Oval Pro XL Automatic Screen Priting Press

The perfect balance of performance, reliability, and scalability within the ROQ Oval lineup.

ROQ Oval Pro XL Automatic Press

Product variants

Operates with the Super Smooth & Efficient Chain Drive
XL+ Models: 24" x 31.5" Print Area
Outputs Up To 900 Pieces per Hour with 2 Operators
ROQ Solid 3 Year Warranty Included

Press Overview:

The ROQ Oval Pro is the ideal bridge between efficiency and advanced production capability, offering enhanced performance, reliability, and control for growing operations.

Positioned between the Oval Run and the flagship Oval Evolution, the Oval Pro delivers increased speed, expanded configuration options, and greater operator control—without the complexity or investment of a full-scale industrial system.

Built for decorators ready to scale beyond entry-level automation, the Oval Pro maintains precise registration, consistent print quality, and dependable output across long production runs.

With support for larger print formats, improved indexing, and user-friendly controls, this platform is designed to help shops increase throughput while maintaining operational simplicity.

Press Available Configurations

The ROQ Oval Pro is available in multiple configurations to match your production needs, scalability goals, and shop layout.

– P16 Configuration: 10 Colors / 16 Stations / 10 Flash Positions

– P20 Configuration: 14 Colors / 20 Stations / 14 Flash Positions

– P24 Configuration: 18 Colors / 24 Stations / 18 Flash Positions

– P32 Configuration: 24 Colors / 32 Stations / 24 Flash Positions

– P36 Configuration: 24 Colors / 36 Stations / 24 Flash Positions

– P38 Configuration: 24 Colors / 38 Stations / 24 Flash Positions

– P44 Configuration: 24 Colors / 44 Stations / 24 Flash Positions

– P50 Configuration: 24 Colors / 50 Stations / 24 Flash Positions

– P56 Configuration: 24 Colors / 56 Stations / 24 Flash Positions

– Custom configurations available, lead times vary.

Press Print Area & Max Frame Size:

Maximum Print Size (XL+ Models): 24" x 31.5"
Maximum Frame Size: ~30" x 45" (760mm x 1150mm class frames)

Press Production Speed:

- Maximum Production Speed: Up to 900 pieces/hour

Press Available Footprint (By Configuration):

(Measured by total machine length based on pallet count)

– P16: 28.8'
– P20: 35.1'
– P24: 41.4'
– P32: 53.9'
– P36: 60.2'
– P38: 63.3'
– P44: 72.7'
– P50: 82'
– P56: 91.4'

– Footprint will vary slightly based on configuration, layout, and auxiliary equipment.

Main Features:

– Aluminum honeycomb pallets for durability and heat resistance
– AC frequency-driven squeegee movement for smooth operation
– Independent control panel on each printhead
– Pneumatic screen holders (U-clamp or pin system options)
– Independent printhead elevation adjustment
– Central touchscreen control panel (15")
– Micro-registration system with vernier scale
– Independent control of print/flood speed, pressure, and angle
– Flash units positioned within printhead stations
– Double Index printing mode
– Double Chain Sprocket

Additional Features:
– Odd/even mode
– Multiprint capability
– Recipe saving system
– Skip function
– Optional 4-cylinder squeegee carriage
– Optional touchscreen upgrades

Press Power Requirements:

– Voltage: 230V / 400V (model & region dependent)
– Frequency: 50 / 60 Hz
– Maximum Consumption: ~6.5 kW – 16 kW (depending on model size)
– Air Consumption:
~130 L/min per printhead @ 7 bar

Press CFM Requirements:

- Air Compressed Consumption: 43-74CFM (depending on configuration)
